Features and Benefits:

• Easy identification - each contact tip is marked showing part no and wire diameter
• Excellent electrical properties
• Inside diameter tolerance is held to +/-.003 in
• Threaded style contact tip to ensure proper contact with a gas diffuser when installed to the MIG gun
• Machined from a copper alloy tubing providing a consistent and smooth inside diameter surface
• Operator appeal with an ergonomic handle with diamond pattern for better grip
• Long-life trigger tested at over 1.2 million cycles without failure
• Rugged steel spring stain relief for durability and robustness



Tweco 14 Series Standard Duty Contact Tip accommodates 0.023-Inch wire and is perfect for use with 200 - 400 A Tweco No.2, No.3, No.4 MIG gun as well as specific MIG gun series. Contact tip with excellent electrical properties is ideal for use in standard welding application up to 400 A. It features part number and wire diameter for easy identification. 1 1/2-Inch Contact tip with 1/4-Inch-28 UNF-2A thread size has 0.038-Inch nominal ID and 1/4-Inch OD. Contact tip is made from extruded or gun-drilled 122 DHP copper alloy and machined from a copper alloy tubing to offer a consistent as well as smooth surface of inside diameter with +/-0.003-Inch tolerance. It has threaded style that ensures proper contact with a gas diffuser when installed to the MIG gun. It comes in slip-on or thread-on nozzle styles with a choice of diameter bore sizes. Contact tip locks in place when twisted and offers better electrical conductivity with increased surface contact. Contact tip features thick-walled design that acts like a heat sink conducting heat away from the arc source. It can be twisted quarter turn clockwise when tip wear point is reached that reveals a new wear point for doubling the life of the tip. Contact tip is sold as 25 per pack.
